SlaByte Plotter S-Cut V60
Experience unmatched precision and efficiency with the S-Cut V60. Designed to handle all materials, from PPF to TINT and VINYL, this machine delivers flawless results every time.
4.3-inch Full Touch High-Definition Display
Clear and Intuitive: Provides a clear and intuitive interface for easy control and monitoring.
Precision and Stability
4-Point Dot Positioning Scanning: Real-time camera capture and automatic correction ensure precise contour cutting.
Silent High Wind Centrifugal Turbine Adsorption Fan: Keeps film tightly in place during cutting, preventing wrinkles and errors.
Versatile Cutting Solution
Handles All Materials: Efficiently cuts PPF, TINT, VINYL, and more, offering a versatile cutting solution.
Automated Roll-Up System
Automated Roll-Up: Automatically rolls the cut film onto the spindle, saving you time and effort, ensuring a seamless workflow, and boosting productivity by reducing downtime.
01
Become a SlaByte Dealer
1. On-Site Installation and Training:
Receive comprehensive on-site installation and training to ensure you and your team are fully equipped.
2. Higher Profit Margins:
Enjoy greater profit margins and exclusive pricing benefits as a SlaByte dealer.
3. Local Marketing Support:
Benefit from tailored local marketing support to boost your sales and brand visibility.
4. Custom OEM Options:
Offer customized OEM solutions to meet the specific needs of your market and customers.
0102030405
Parameter
| MODEL | SlaByte Plotter S-Cut V60 |
| motherboard | 128 bit servo dual control intelligent chip |
| control panel | 4.3-inch full touch high-definition mobile phone display screen |
| drive | Imported dual silent servo system |
| feed method | High precision imported integrated steel spindles |
| Origin positioning | Clearance system, any origin setting |
| Positioning method | 4-point dot positioning scanning, real-time camera capture, automatic correction, automatic contour cutting |
| Maximum feed width | 1650mm |
| Maximum cutting width | 1550mm |
| Maximum cutting speed | 1500mm/s |
| Maximum cutting length | Infinite length |
| Maximum cutting thickness | 1mm |
| Knife pressure | 0-2000g（Digital adjustment) |
| Adsorption fan power | 12V 0.6A -0.8A Silent High Wind Centrifugal Turbine Adsorption Fan |
| Adsorption capacity | 60 CFM-6 level -18.8/m2 |
| Mechanical accuracy | 0.01mm |
| Repetitive accuracy | 0.01mm |
| Types of drawing pens | Various water-based, oil-based, atomic drawing pens, poster pens with a diameter of 11.4mm |
| Drawing instruction | DM-PL/HP-GL automatic recognition |
| Knife holder/cutting blade | Various types of knife holders with a diameter of 11.4mm * 26mm~30mm, Roland 20/30/45/60 degrees with a blade diameter of 1.8mm, and other sharp knives of the same model can be used interchangeably |
| data interface | Ethernet port/USB2.0/U storage card |
| Fully automatic film winding system (complete set) | Gear reduction speed control motor |
| Film winding motor power/voltage | 220V/50Hz-60Hz/10W-40W/150mA |
| Reduction ratio of film rolling motor | 3:1-10000:1，1uF/500V |
| Rated speed of film winding motor | 1450r/min, IP20 B |
| Host voltage/power supply | AC110V /220V±10%，50Hz-60Hz |
| power consumption | ＜350W |
| Operating environment | Temperature:+5-+35, relative temperature 30% -70% |
| Packaging size | 2000*550*460mm(Wooden frame size) |
| Installation dimensions | 2000*1300*1300mm |
| G.W | (Heavy bracket)85kg |
| N.W | 80kg |
| CBM | (0.5m³) |
